Type test Switchgear
Last updated: 4 May 2025
5 Views
Type test Switchgear
1.) Dielectric Properties
2.) Ratio Interference Test
3.) Measurement of the Resistance Main Circuit
4.) Temperature Rise Limit Test
5) Short-Circuit Current Withstand Test
6.) Verification of the Degree of Protection Test
7.) Effectiveness of the protective circuit
8.) Mechanical Operation Test
9.) Short_Circuit Duties Test
10.) Capacitive Current Switching Test
11.) Environmental Test
12.) Critical Current Test
13.) Short Line Fault Test
14.) Out-of Phase Making and Breaking Test
